1. Rated speed:a)1:1 V≤2.5 m/s;b)2:1 V≤1.0 m/s.
2. Rated load:a)1:1 Q=630~1250 kg;b)2:1 Q=1400~2000 kg.
3. System mass:a)1:1 1933~5200 kg;b)2:1 3010~6273 kg.
4. Rope Dia diamer:8~16 mm.
Other specifications for mechanical rope brake:
1. The braking wire travel when the eccentric wheel is released:≤10mm.
2. Releasing force of the eccentric wheel:≤150 N.
3. Tripping distance of the governor:15~25 mm.
4. Force of the braking wire of governor:≥240 N.
Other specifications for electromagnetic rope brake
1. Rated Voltage:DC1,24 V;
2. Power:≤50 W;
3. Current:≤3A.
