1. Rated speed:a)1:1 V≤2.5 m/s;b)2:1 V≤1.0 m/s.
2. Rated load:a)1:1 Q=200~1250 kg;b)2:1 Q=400~2500 kg.
3. System mass:a)1:1 900~4525 kg;b)2:1 1280~7450 kg.
4. Rope Dia diamer:10~13 mm
Other specifications for mechanical rope brake:
1. The braking wire travel when the eccentric wheel is released:≤10 mm
2. Releasing force of the eccentric wheel:50-120 N.
3. Tripping distance of the governor:15~25 mm.
4. Force of the braking wire of governor:≥240 N.
Other specifications for electromagnetic rope brake:
1. Rated Voltage:AC,110 V;
2. Power:≤50 W;
3. Current:≤1.5A.
