| Standard | Construction & Size | Tolerance on Diameter | Tension Strength (MPa) | Minimum Breaking Load(KN) | Other Special Performance | Usage | |
| 12385-5 |
|
6×19S+FC-6.0mm | 1.94 | 1770 | 21 |
|
Governor Rope |
|
8×19S+FC-8mm | 1.94 | 1370/1770 | 28.1 |
|
Hoisting,Governor Rope | |
| 8×19S+FC-9.5mm | 1.94 | 1370/1770 | 39.7 |
|
Governor Rope | ||
| 8×19S+FC-10mm | 1.94 | 1370/1770 | 44 | Passing 600,000 Times Fatigue Test Acc to OTIS 51111 Standard | Hoisting Rope | ||
| 8×19S+FC-11mm | 1.95 | 1370/1770 | 53.2 |
|
Hoisting Rope | ||
| 8×19S+FC-13mm | 1.95 | 1370/1770 | 74.3 |
|
Hoisting Rope | ||
| 8×19S+FC-16mm | 1.95 | 1370/1770 | 113 |
|
Hoisting Rope | ||
|
8×25Fi+FC-12.7mm | 1.95 | 1370/1770 | 74.3 |
|
Compensation Rope | |
| 8×25Fi+FC-16mm | 1.95 | 1370/1770 | 113 |
|
Compensation Rope | ||
|
6×25Fi+FC-16mm | 1.95 | 1770 | 150 |
|
Compensation Rope | |
