| Standard | Construction& Size | Tolerance on Diameter | Tension Strength (MPa) | Minimum Breaking Load(KN) | Other Special Performance | Usage | |
| SCHINDLER SN211405 KONE AND THYSSEN STANDARD |
|
6×19S+FC-6.3mm | 1.94 | 1960 | 25.7 |
|
Governor Rope |
|
8×19S+FC-8mm | 1.94 | 1370/1770 | 28.1 |
|
Hoisting Rope | |
| 8×19S+FC-10mm | 1.94 | 1370/1770 | 44 |
|
Hoisting Rope | ||
| 8×19S+FC-11mm | 1.95 | 1370/1770 | 53.2 |
|
Hoisting Rope | ||
| 8×19S+FC-13mm | 1.95 | 0.8 | 74.3 | Passing 600,000 Times Fatigue Test Acc to OTIS 51111 Standard | Hoisting Rope | ||
| 8×19S+FC-16mm | 1.95 | 1370/1770 | 113 |
|
Hoisting Rope | ||
|
6×25Fi+FC-10mm | 0-+7% | 1620 | 54.4 |
|
Governor Rope | |
| 6×25Fi+FC-16mm | 1.95 | 1770 | 150 |
|
Compensation Rope | ||
|
8×25Fi+FC-12.7mm | 1.95 | 1370/1770 | 74.3 |
|
Compensation Rope | |
| 8×25Fi+FC-16mm | 1.95 | 1370/1770 | 113 |
|
Compensation Rope | ||
|
8×19S+IWRC-13mm | 0-+2% | 1370/1770 | 94.5 | Passing 1,200,000 Times Fatigue Test Acc to OTIS 51111 Standard | Hoisting Rope | |
|
9×19S+IWRC-13mm | *0-+2% | 1370/1770 | 104.4 | Passing 1,200,000 Times Fatigue Test Acc to OTIS 51111 Standard | Hoisting Rope | |
