| Standard | Construction& Size | Tolerance on Diameter | Tension Strength (MPa) | Minimum Breaking Load(KN) | Other Special Performance | Usage | |
| JIS G3525 CLASS E |
|
8×19S+FC-8mm | 0-+10% | 1320/1770 | 26 | Hardness HV0.5=360±20 | Governor Rope |
| 8×19S+FC-10mm | 0-+7% | 1320/1770 | 40.6 | Hardness HV0.5=360±20 | Hoisting Rope | ||
| 8×19S+FC-12mm | 0-+5% | 1320/1770 | 58.5 | Hardness HV0.5=360±20 | Hoisting Rope | ||
| 8×19S+FC-14mm | 0-+5% | 1320/1770 | 79.6 | Hardness HV0.5=360±20 | Hoisting Rope | ||
| 8×19S+FC-16mm | 0-+5% | 1320/1770 | 104 | Hardness HV0.5=360±20 | Hoisting Rope | ||
| 8×19S+FC-19mm | 0-+7% | 1320/1770 | 147 |
|
Hoisting Rope | ||
| JIS G3525 CLASS A |
|
6×25Fi+FC-8mm | 0-+5% | 1620 | 34.9 |
|
Governor Rope |
| GB 8903 |
|
8×19S+FC-8mm | 1.94 | 1770 | 33.2 |
|
Hoisting Rope |
| 8×19S+FC-11mm | 1.95 | 1770 | 62.8 |
|
Hoisting Rope | ||
| 8×19S+FC-13mm | 1.95 | 1770 | 87.6 |
|
Hoisting Rope | ||
| 8×19S+FC-16mm | 1.95 | 1770 | 133 |
|
Hoisting Rope | ||
