| Item No. |
ZT82S- 800/4-T2 |
ZT90- 1500/4-T2 |
|
| Rated Voltage (V) | DC110 | DC110 | |
| Rated Current (A) | 2*0.93 | 2*1.25 | |
| Push Power (N) | ≥800 | ≥1500 | |
| Stroke (mm) | 4 | 4 | |
| Operation method / Insulation Grade | S4/F | S4/F | |
| Overall dimensions and Installation size (mm) | A | 196 | 250 |
| B | 76 | 80 | |
| C | 50 | 54 | |
| D | 150 | 150 | |
| E | 124 | 125 | |
| F | 82 | 90 | |
| G | Ø128 | Ø149 | |
| H | 4 | 3.5 | |
| I | 185 | 202 | |
