| Model | TK-32Y | TKD-32Y | TK-32Y/Q | TKD-32Y/Q |
| Rated Cool Capaticy(W ) | 3200 | 3200 | 3200 | 3200 |
| Rated Heat Capacity(W ) | / | 2200 | / | 2200 |
| Air Flow (high/low, m3/h ) | 530/430 | 530/430 | 530/430 | 530/430 |
| Rated Cool Input Current(A) | 5.8 | 5.8 | 5.8 | 5.8 |
| Rated Cool Input power (W ) | 1200 | 1200 | 1200 | 1200 |
| Rated Heat Input Current(A) | / | 10.3 | / | 10.3 |
| Rated Heat Input Power (W ) | / | 2255 | / | 2255 |
| Voltage/Frequency | 220V~50Hz | 220V~50Hz | 220V~50Hz | 220V~50Hz |
| Noise dB (A ) | <55 | <55 | <55 | <55 |
| Water Proof Level | IPX4 | IPX4 | IPX4 | IPX4 |
| Insulated Voltage Grade | I | I | I | I |
| Compressor Protection | Overheat protection; Over current protection; Delay startup protection | |||
| Control Mode | Program control (automatically ) +infrared remote control (Manually ) | |||
| Dimensions (L*W*H)mm | 640*570*510 | 640*570*510 | ||
| Weight(kg) | 59 | 59.5 | 59 | 59.5 |
| For Elevator Load Capacity(kg) | >1350 | >1350 | >1350 | >1350 |
| Air Out,Air Return | From two side,to front | from front ,to front | ||
Installation Brief:
1 Air conditioner main machine installed directly on the elevator upper beam, or fix with rack to the upper beam ;
2 Return air from elevator car;
3 Cool air delivered into car with heat insulation duct;
4 Insulation done in the interlayer, prevent from forming condensation water;
5 The remote receive probe pulled into car and fixed;
6 No blockage to cool air outlet.
