TKF-25Y split elevator air conditioner parmeter :
| Rated Cool Capaticy (W ) | 2500W | |
| Air Flow (m3/h ) | 480 (high wind ) / 360 (low wind ) m 3 /h | |
| Rated Input Current (A ) | 4.7A | |
| Rated Input power (W ) | 1015w | |
| Voltage/Frequency | 220V - 50Hz | |
| Noise dB (A ) | Main unit ＜ 55 dB (A ) | subsidiary ＜ 50 dB (A ) |
| Dimensions (L*W*H ) mm | Main machine | subsidiary |
| 450*310*395 (mm) | 556*238*235(mm ) | |
| Air out Opening Size | 435* 45mm | |
| Return Air Opening Size | Ñ„ 200mm circular hole or 620mm perimeter ellipse | |
| Weight (kg ) | Main machine 31.5 (Kg ) | subsidiary 15.5 m (Kg ) |
| For Elevator (kg ) | ≤ 1350kg | |
Brief Installing introduction:
1 ． the main machine of the elevator air conditioner are installed on the upper beam of the elevator or fix by the rack to the upper beam.
2 ． open an 200mm hole on the elevator car top for returning air.
3 ． Tear off the original fan, heat insulating dealing to the car top interlayer, fix the subsidiary to the fan opening.
4 ． lead the core of the remote receiving probe to car and fix it ;
5 ． connect the copper pipe,condensate water pipe and electricity wire between the major machine and the subsidiary ;
6 ． screw open the adjust vavle, discharge the air in the pipe and screw tight it ;
7 ． Connect the power supply, use remote controller to set the running mode of “program controlâ€, the air conditioner goes into auto running mode.
