Fast and easy to install
Their placement is suitable whatever the separation among the cables ideal in those cables with excessive separation
It doesn't produce frictions neither displacements along the cable
Easy calibration with no need for known weights
Suitable for use with any wire rope diameter form 06~16mm
UnSymmetrical Duplex Serial CommunicationBUSUSDSC-BUS
Analog output 0~10V. -10~10V
Analog output 4~20mA (*OMS-320)
| Technical data loadsensorLS | Technical data control unit RMW-112 | ||
| Rope diameter | 6mm~16mm(A) | Power supply voltage | AC/DC14V~65V |
| Measuring range | 0~500kg | Power dissipation | ≤4W |
| Breaking load | 1.5 | Alarm relays | Light load,over load |
| Connection cable | USB-port (2m) | Analog voltage output | 0~10V,-10~10V |
| Temperature range | 0℃~70℃ | Analog current output | 4~20mA |
