Fast and easy to install
Suitable for use with different rope diameters and types
Their placement is suitable whatever the separation among the cables ideal in those cables with excessive separation
It doesn't produce frictions neither displacements along the cable
Auto-calibrate tension control of the cables load limitation
UnSymmetrical Duplex Serial Communication BUS(USDSC-BUS)
| Technical data loadsensor | Technical data control unit 920 | ||
| Rope diameter | 6mm~16mm(A) | Power supply voltage | AC/DC14V~65V |
| Measuring range | 0~500kg | Power dissipation | ≤4W |
| Breaking load | 1.5 | Alarm relays | Light load,over load |
| Connection cable | USB-port (2m) | Analog voltage output | / |
| Temperature range | 0℃~70℃ | Analog current output | / |
