Suitable for use with different rope diameters and types
No calibration necessary
12measuring channels
Load distribution alarm
USB-port
software-wizard for optimum rope-tension settings
| Technical data loadsensorLS | Technical data control unit RMW-112 | ||
| Rope diameter | 6mm~16mm(A) | Power supply voltage | AC/DC14V~65V LR6,AA |
| Measuring range | 0~2000kg | Power dissipation | ≤4W |
| Breaking load | 1.5 | Measuring channels | 12 |
| Connection cable | USB-port (2m) | Bandwidth | 30Hz |
| Temperature range | 0℃~70℃ | Sampling rate | 100Hz |
