A miniaturized design
Suitable for use with any wire rope diameter form 06-16mm
Large LCD display with backlight
Up to 8 independent channels for measuring up to 8 ropes at the same time
Slack rope alarm
Load distribution alarm
| Technical data loadsensorLM | Technical data control unit 620 | ||
| Rope diameter | 6mm~16mm(A) | Power supply voltage | AC/DC14V~65V |
| Measuring range | 0~500kg | Power dissipation | ≤4W |
| Breaking load | 1.5 | Alarm relays | Light load,over load |
| Connection cable | USB-port (2m) | Analog voltage output | 8 |
| Temperature range | 0℃~70℃ | Analog voltage¤t output | 0~10V,-10~10V 4~20mA |
